Antenna QuSector 17HV-90-2
To check PN please select variant below
QuSector 17HV-90-2 offers a 90 degrees, 17dBi gain signal with four dual-band connectors. It is a perfect indoor and outdoor device for industrial installations.
QuSector 17HV-90-2 is a concurrent, dual-band, H&V polarity, MIMO 2x2 panel antenna. It simultaneously operates at 2.4GHz with 14dBi gain and 5GHz with 17dBi gain. Due to its high gain, it can be used on short or medium distances, for example for hotspots in schools, stadiums, offices or public places. High quality injection moulded enclosure allows to implement it alongside with indoor and IP67 outdoor solutions.
The antenna comes in three configurations: with 4*70cm (28inch) cables terminated with Nm, RPSMA or RPTNC connectors.
QuSector 17HV-90-2 was designed to be a perfect match for your access point.
Variants:
Why QuSector 17HV-90-2
Outdoor antenna works in any weather conditions, IP67
Antenna perfectly matched with the router
Wall or mast mounting system with two planes, 60 degrees regulation
Made in Europe
SPECIFICATION
PLOTS
VSWR
Gain
Elevation
Azimuth
Elevation
Azimuth
Elevation
Azimuth
Elevation
Azimuth
DIMENSIONS
-cable.png "Dimensions of QuSector 17HV-90-2")
-cable.png "Dimensions of QuSector 17HV-90-2")
