Antenna QuOmni LTE SISO

To check PN please select variant below

Omnidirectional multiband LTE SISO antenna

QuOmni LTE omnidirectional SISO LTE antenna working in Vertical polarization. It´s desired for LTE/3G/2G connections. The antenna can be used for the most popular LTE bands (e.g. 3,7,20) and frequencies 694-2700 MHz. This antenna is predicted to be installed on the buildings (on the pole or on the wall) as a client antenna or on a moving points like trains, buses, lorries, yachts or boats to receive Internet by LTE/3G. Using SMA connectors makes it compatible with most LTE devices, like Teltonika: RUT230, TRB140, TRB141, TRB142, TRB145, TRM240, TRM250 and other SISO LTE/3G/2G modems and routers.

Variants:

5m

10m

Why QuOmni LTE SISO

Learn more about your profit

Outdoor antenna works in any weather conditions, IP68

Galvanized steel, wall or pole mounting bracket

SMA connector

360° beamwidth

4dBi gain

Made in Europe

QuOmni LTE SISO

SPECIFICATION

PRODUCT DETAILS

LTE ANTENNA SPECIFICATION

MECHANICAL SPECIFICATION

FREQUENCY BANDS

COMPATIBLE ROUTERS

Frequency

694 - 960 MHz

1.7 - 2.2 GHz

2.2 - 2.7 GHz

Gain

694 - 960 MHz : 2 dBi

1.7 - 2.2 GHz : 2 dBi

2.2 - 2.7 GHz : 4 dBi

Supported LTE/5G bands

1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 23, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 44, 53, 59, 62, 65, 66, 67, 68, 69, 85, n80, n81, n82, n83, n84, n86, n89, n90, n95

VSWR

<1.60, max <2.00

Beamwidth

360°/35° ±5°

Polarization

Vertical

Impedance

50 Ω

PLOTS

PRODUCT DETAILS

VSWR

VSWR of QuOmni LTE SISO

Gain

Gain of QuOmni LTE SISO
From 700MHz to 900MHz
Elevation
Azimuth
From 1.71GHz to 2.17GHz
Elevation
Azimuth
From 2.3GHz to 2.7GHz
Elevation
Azimuth

ANY QUESTIONS?

contact us

DIMENSIONS

PRODUCT DETAILS
QuOmni LTE SISOQuOmni LTE SISO
QuOmni LTE SISOQuOmni LTE SISO

WHAT'S IN THE BOX?

PRODUCT DETAILS

IN THE BOX

QuOmni LTE SISO

Parts of QuOmni LTE SISO
1 x
Parts of QuOmni LTE SISO
2 x M8
Parts of QuOmni LTE SISO
1 x
Parts of QuOmni LTE SISO
4 x M6 x 10
Parts of QuOmni LTE SISO
4 x
Parts of QuOmni LTE SISO
1 x

Download

Datasheet QuOmni LTE SISO
Download
3D MODEL
Download
Installation Guide
Download
IP67 Certificate
Download
IP68 Certificate
Download
IK08 Certificate
