1. What is an omnidirectional antenna?

Type of antenna which receives or transmits signals in all directions along one plane with equal strength. Thank to that you can recive signal from whenever you are in particular area. Omnidirectioanl antenna radiation pattern:

IPXY is an Ingress Protection Rating, which defines protection levels of certain product. X from 0-6 defines security level from penetration of solids. Y from 0-9 defines security level from water.

3. Why placing router and antenna in one enclosure is better?

The biggest benefit of router and antenna being next to each other is the reduction of cable used to connect the elements. Reducing the cable length reduces its loss, which has high impact on signal quality.

Porównaj

Antenna QuCam for RUT2xx Global

P/n: C2240MUS

Outdoor CCTV LTE PoE gateway Global with embedded LTE router & PoE switch for CCTV cameras.

QuCam for RUT2xx Global is a powerful outdoor industrial gateway for professional CCTV application with embedded PoE switch for up to 3x CCTV cameras and place to install Teltonika RUT200, RUT240, RUT241 or RUT260 (not included in gateway set). QuCam for RUT2xx also has integrated omnidirectional LTE and Wi-Fi antennas. The mobile router delivers high performance for mission-critical cellular communication in harsh and hazardous environments where a wide operating temperature is required. Equipped with an external SIM holder.

Technical specification

Any question?

Why QuCam for RUT2xx Global

Learn more about your profit

Passive PoE input 48V ~ 58V

3 x active PoE output (802.3 af / at)

SIM card slot

Outdoor antenna works in any weather conditions, IP67

Mounting system with two planes, 60 degrees regulation

Made in Europe

SPECIFICATION

PRODUCT DETAILS

Frequency

617 - 960 MHz

1.7 - 2.7 GHz

3.3 - 4.7 GHz

5.2 - 6.0 GHz

Gain

617 - 960 MHz : 3 dBi

1.7 - 2.7 GHz : 4 dBi

3.3 - 4.7 GHz : 4.5 dBi

5.2 - 6.0 GHz : 2.5dBi

Supported LTE/5G bands

1, 2, 3, 4, 5, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 22, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 47, 48, 49, 52, 53, 65, 66, 67, 68, 69, 71, 85, 103, 106, n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n34, n38, n39, n40, n41, n47, n48, n53, n65, n66, n67, n71, n77, n78, n80, n81, n82, n83, n84, n85, n86, n89, n90, n95, n97, n98, n100, n101, n256

VSWR

<1.80, max <2.00

Beamwidth

360°/35° ±5°

Polarization

Vertical

Impedance

50 Ω

Connector

2x SMA

Cable type

RG316

PLOTS

PRODUCT DETAILS

VSWR FOR WI-FI ANTENNA

VSWR FOR 5G/LTE ANTENNA

GAIN FOR WI-FI ANTENNA

GAIN FOR 5G/LTE ANTENNA

5G/LTE from 650MHz to 950MHz

Elevation

Azimuth

5G/LTE from 1.71GHz to 2.5GHz

Elevation

Azimuth

5G/LTE from 3.3GHz to 4.0GHz

Elevation

Azimuth

5G/LTE from 4.5GHz to 5.5GHz

Elevation

Azimuth

Wi-Fi 2.4GHz to 6.5GHz

Elevation

Azimuth

ANY QUESTIONS?

DIMENSIONS

PRODUCT DETAILS

WHAT'S IN THE BOX?

PRODUCT DETAILS

IN THE BOX

QuCam for RUT2xx Global

1 x

2 x

1 x

2 x

1 x M6 X 18

2 x M8

1 x

4 x

Designed For

Download

Datasheet QuCam for RUT2xx Global

Download

240SM Kit Quick Start Guide

Download

USE CASES

BEST SPOTS FOR YOUR ANTENNA

FREQUENTLY ASKED QUESTIONS

FIND ANSWERS

CAN'T FIND THE ANSWER FOR YOUR QUESTION?

Antenna QuCam for RUT2xx Global

Outdoor CCTV LTE PoE gateway Global with embedded LTE router & PoE switch for CCTV cameras.

Why QuCam for RUT2xx Global

SPECIFICATION

5G/LTE ANTENNA SPECIFICATION

Wi-Fi Antenna Specification

PoE Switch Specification

Power Supply Electrical Input Specification

Power Supply Electrical Output Specification

Power Supply Mechanical Specification

Mechanical Specification

Mounting Kit

COMPATIBLE ROUTERS
