Antenna QuSpot for Robustel R3000 Lite

P/n: AR3000LS

INTEGRATED MULTI-BAND LTE OMNI ANTENNA + POE SPLITTER + PLACE TO INSTALL ROBUSTEL R3000 Lite (ALL-IN-ONE)

QuSpot all-in-one antenna for Robustel R3000 Lite router is a perfect outdoor device for mobile and fixed installations like industrial, public, CCTV, hotspots, yachts, boats, campers, RV etc. It has embedded omni LTE antenna. If you use R3000 Lite with QuSpot antenna, you get an integrated complete solution with embedded router and multi band antennas in one enclosure.

The set contains a Passive PoE splitter, allowing you to split data and power from a single Ethernet cable and maintain gigabit transfer speeds while protecting the LAN port from damage caused by overvoltage, short circuit or improper connection.

Why QuSpot for Robustel R3000 Lite

Learn more about your profit

Outdoor antenna works in any weather conditions, IP68

Galvanized steel, wall or pole mounting bracket

ANTENNA PERFECTLY MATCHED WITH THE ROBUSTEL R3000 LITE

ALL ANTENNAS AND ROBUSTEL ROUTER INTEGRATED IN ONE ENCLOSURE

Made in Europe

QuSpot for Robustel R3000 Lite

SPECIFICATION

PRODUCT DETAILS

LTE ANTENNA SPECIFICATION

MECHANICAL SPECIFICATION

FREQUENCY BANDS

COMPATIBLE ROUTERS

Frequency

694 - 960 MHz

1.7 - 2.2 GHz

2.2 - 2.7 GHz

Gain

694 - 960 MHz : 2 dBi

1.7 - 2.2 GHz : 2 dBi

2.2 - 2.7 GHz : 4 dBi

Supported LTE/5G bands

1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 23, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 44, 53, 59, 62, 65, 66, 67, 68, 69, 85, n80, n81, n82, n83, n84, n86, n89, n90, n95

VSWR

<1.60, max <2.00

Beamwidth

360°/35° ±5°

Polarization

Vertical

Impedance

50 Ω

PLOTS

PRODUCT DETAILS

VSWR

VSWR of QuSpot for Robustel R3000 Lite

Gain

Gain of QuSpot for Robustel R3000 Lite
From 700MHz to 900MHz
Elevation
Azimuth
From 1.71GHz to 2.17GHz
Elevation
Azimuth
From 2.3GHz to 2.7GHz
Elevation
Azimuth

ANY QUESTIONS?

contact us

DIMENSIONS

PRODUCT DETAILS
QuSpot for Robustel R3000 LiteQuSpot for Robustel R3000 Lite
QuSpot for Robustel R3000 LiteQuSpot for Robustel R3000 Lite

Download

Datasheet QuSpot for Robustel R3000 Lite
Download
3D MODEL
Download
Installation Guide
Download
IP67 Certificate
Download
IP68 Certificate
Download
IK08 Certificate
Download
