QuPS2

P/N: QPSP2

Outdoor power socket & plug - 2 PIN set

Outdoor power socket & plug 2 PIN set for all cases where the User doesn’t want to use Passive PoE powering feature in all QuWireless antennas.

Technical specification

Any question?

Contact us

Why QuPS2

Learn more about your profit

Works in any weather conditions, IP68

Connection directly to DC power source

Power and Data IN/OUT connection (2 pins)

QuPS2

SPECIFICATION

PRODUCT DETAILS

Mechanical Specification

Maximum current

5A

Maximum voltage

200V

Temperature range

-25…70°C

Minimum mating cycle

500x

Minimum mating cycle for Molex connector

250x

Ingress protection

IP68

Connector Type

SP1310/P2I-N, 2 pin

Micro-Fit 3.0, 4 pin (2x2)

SP1310 Connector Materials

Internal contacts material: Brass

Internal contact finishing: Gold

Micro-Fit 3.0 Connector Materials

Internal contacts material: Phosphor bronze

Internal contact finishing: Tin

Cable type

H05VV-F (OWY) 300/500V

2 cores 0,5mm², stranded wire, diameter 8mm, length 150mm

Connector Pinout

1 - Power (+)

2 - GND (-)

Connector flammability class

UL94V-0 flammability class of plastic housing

RoHS Compliance

Directive 2011/65/EU

Directive 2015/863

Weight

0.0205 ± 0.005 kg

0.0451 ± 0.011 lbs
